Постановка задачи:
Набор данных Digits библиотеки scikit-learn предоставляет многочисленные наборы данных, которые полезны для тестирования многих задач анализа данных и прогнозирования результатов. Некоторые ученые утверждают, что он точно предсказывает цифру в 95% случаев. Выполните анализ данных, чтобы принять эту гипотезу.
Импорт необходимых библиотек:
#importing libraries import numpy as np import matplotlib.pyplot as plt import seaborn as sns from sklearn import svm from sklearn.neighbors import KNeighborsClassifier from sklearn.linear_model import LogisticRegression from sklearn.ensemble import RandomForestClassifier import warnings warnings.filterwarnings("ignore")
Импорт набора данных из библиотеки Sk-learn:
# Importing dataset from sk-learn library from sklearn import datasets digits = datasets.load_digits()
Описание набора данных:
# Description of dataset print(digits.DESCR) .. _digits_dataset: Optical recognition of handwritten digits dataset -------------------------------------------------- **Data Set Characteristics:** :Number of Instances: 1797 :Number of Attributes: 64 :Attribute Information: 8x8 image of integer pixels in the range 0..16. :Missing Attribute Values: None :Creator: E. Alpaydin (alpaydin '@' boun.edu.tr) :Date: July; 1998 This is a copy of the test set of the UCI ML hand-written digits datasets https://archive.ics.uci.edu/ml/datasets/Optical+Recognition+of+Handwritten+Digits The data set contains images of hand-written digits: 10 classes where each class refers to a digit. Preprocessing programs made available by NIST were used to extract normalized bitmaps of handwritten digits from a preprinted form. From a total of 43 people, 30 contributed to the training set and different 13 to the test set. 32x32 bitmaps are divided into nonoverlapping blocks of 4x4 and the number of on pixels are counted in each block. This generates an input matrix of 8x8 where each element is an integer in the range 0..16. This reduces dimensionality and gives invariance to small distortions. For info on NIST preprocessing routines, see M. D. Garris, J. L. Blue, G. T. Candela, D. L. Dimmick, J. Geist, P. J. Grother, S. A. Janet, and C. L. Wilson, NIST Form-Based Handprint Recognition System, NISTIR 5469, 1994. .. topic:: References - C. Kaynak (1995) Methods of Combining Multiple Classifiers and Their Applications to Handwritten Digit Recognition, MSc Thesis, Institute of Graduate Studies in Science and Engineering, Bogazici University. - E. Alpaydin, C. Kaynak (1998) Cascading Classifiers, Kybernetika. - Ken Tang and Ponnuthurai N. Suganthan and Xi Yao and A. Kai Qin. Linear dimensionalityreduction using relevance weighted LDA. School of Electrical and Electronic Engineering Nanyang Technological University. 2005. - Claudio Gentile. A New Approximate Maximal Margin Classification Algorithm. NIPS. 2000. # shape of dataset print(digits.data.shape) out: (1797, 64) # ploting single digit image plt.gray() plt.matshow(digits.images[0],cmap=plt.cm.hot,interpolation = 'nearest') plt.show()
Чтобы применить классификатор к этим данным, нам нужно сгладить изображения, превратив каждый двумерный массив значений оттенков серого из формы (8, 8) в форму (64,). Впоследствии весь набор данных будет иметь форму (выборка, признаки), где образец — это количество изображений, а признаки — общее количество пикселей в каждом изображении.
# flatten the images sample = len(digits.images) data = digits.images.reshape((sample, -1)) print(data.view()) out: [[ 0. 0. 5. ... 0. 0. 0.] [ 0. 0. 0. ... 10. 0. 0.] [ 0. 0. 0. ... 16. 9. 0.] ... [ 0. 0. 1. ... 6. 0. 0.] [ 0. 0. 2. ... 12. 0. 0.] [ 0. 0. 10. ... 12. 1. 0.]]
Разделение обучения и тестирования:
# spliting data in training and testing split from sklearn.model_selection import train_test_split x_train, x_test, y_train, y_test = train_test_split(data, digits.target,test_size = 0.3,random_state=0)
Набор данных digits состоит из изображений цифр размером 8x8 пикселей. Атрибут images набора данных хранит массивы значений оттенков серого 8x8 для каждого изображения. Мы будем использовать эти массивы для визуализации изображений.
Визуализация цифр от 0 до 9
# Visualization of digits plt.figure(figsize=(18,9)) for index,(image,label) in enumerate(zip(digits.data[0:10], digits.target[0:10])): plt.subplot(2,5,index+1) plt.imshow(np.reshape(image,(8,8)),cmap=plt.cm.gray) plt.title('Digit %d\n'% label, fontsize =15 )
Прогнозирование с использованием:
1.SVC (классификатор опорных векторов)
# creating the model svc = svm.SVC(gamma=0.001, C=100.) # fitting the svc model svc.fit(x_train,y_train) #Prediction y_pred = svc.predict(x_test) # test sample pridiction _, axes = plt.subplots(nrows=1, ncols=4, figsize=(10, 3)) for ax, image, prediction in zip(axes, x_test, y_pred): ax.set_axis_off() image = image.reshape(8, 8) ax.imshow(image, cmap=plt.cm.gray_r, interpolation='nearest') ax.set_title(f'Prediction: {prediction}') # save the figure plt.savefig('plot7.png', dpi=300, bbox_inches='tight')
Отчет о классификации SVC и матрица путаницы
#using classification report and confusion matrix from sklearn.metrics import confusion_matrix, classification_report svc_confusion = confusion_matrix(y_test,y_pred) print(f'Confusion matrix: \n{svc_confusion}\n\n') print(f'Classification Report: \n{classification_report(y_test,y_pred)}') Confusion matrix: [[45 0 0 0 0 0 0 0 0 0] [ 0 52 0 0 0 0 0 0 0 0] [ 0 0 52 0 0 0 0 1 0 0] [ 0 0 0 54 0 0 0 0 0 0] [ 0 0 0 0 48 0 0 0 0 0] [ 0 0 0 0 0 55 1 0 0 1] [ 0 0 0 0 0 0 60 0 0 0] [ 0 0 0 0 0 0 0 53 0 0] [ 0 1 0 0 0 0 0 0 60 0] [ 0 0 0 0 0 1 0 0 0 56]] Classification Report: precision recall f1-score support 0 1.00 1.00 1.00 45 1 0.98 1.00 0.99 52 2 1.00 0.98 0.99 53 3 1.00 1.00 1.00 54 4 1.00 1.00 1.00 48 5 0.98 0.96 0.97 57 6 0.98 1.00 0.99 60 7 0.98 1.00 0.99 53 8 1.00 0.98 0.99 61 9 0.98 0.98 0.98 57 accuracy 0.99 540 macro avg 0.99 0.99 0.99 540 weighted avg 0.99 0.99 0.99 540
Тепловая карта отчета о классификации и матрица путаницы для классификатора SVC
# heatmap for SVC classifier plt.figure(figsize=(8,6)) s1=sns.heatmap(svc_confusion,square=True, annot=True,cmap='nipy_spectral_r', fmt='d', cbar=True) plt.title('Confusion Matrix for SVC',fontsize = 15) plt.xlabel('Predicted label', fontsize =15) plt.ylabel('True label', fontsize =15)
# SVC accuracy score svc_score = svc.score(x_test, y_test) print('SVC accuracy score:',svc_score*100) SVC accuracy score: 99.07407407407408
Показатель точности SVC: 99,07407407407408
2. Классификатор KNN (K-ближайших соседей)
# creating the model knn = KNeighborsClassifier() # training the model knn.fit(x_train,y_train) # pridiction knn_y_predict = knn.predict(x_test) #Accuracy score knn_score = knn.score(x_test, y_test)
Отчет о классификации KNN и матрица путаницы
#using classification report and confusion matrix from sklearn.metrics import confusion_matrix, classification_report knn_confusion = confusion_matrix(y_test,knn_y_predict) print(f'Confusion matrix: \n{knn_confusion}\n\n') print(f'Classification Report: \n{classification_report(y_test,knn_y_predict)}') Confusion matrix: [[45 0 0 0 0 0 0 0 0 0] [ 0 51 0 0 0 1 0 0 0 0] [ 0 0 52 0 0 0 0 1 0 0] [ 0 0 1 53 0 0 0 0 0 0] [ 0 0 0 0 47 0 0 1 0 0] [ 0 0 0 0 0 55 1 0 0 1] [ 0 0 0 0 0 0 60 0 0 0] [ 0 0 0 0 0 0 0 53 0 0] [ 0 1 0 1 0 0 1 0 58 0] [ 0 0 0 0 0 1 0 0 0 56]] Classification Report: precision recall f1-score support 0 1.00 1.00 1.00 45 1 0.98 0.98 0.98 52 2 0.98 0.98 0.98 53 3 0.98 0.98 0.98 54 4 1.00 0.98 0.99 48 5 0.96 0.96 0.96 57 6 0.97 1.00 0.98 60 7 0.96 1.00 0.98 53 8 1.00 0.95 0.97 61 9 0.98 0.98 0.98 57 accuracy 0.98 540 macro avg 0.98 0.98 0.98 540 weighted avg 0.98 0.98 0.98 540 # heatmap for KNN Classifier plt.figure(figsize=(8,6)) sns.heatmap(knn_confusion,square=True, annot=True,cmap='nipy_spectral_r', fmt='d', cbar=True) plt.title('Confusion Matrix for KNN',fontsize = 15) plt.xlabel('Predicted label', fontsize =15) plt.ylabel('True label', fontsize =15)
KNN accuray score: 98.14814814814815
Классификатор K-ближайших соседей обеспечивает точность 98,14 %
3. Логистическая классификация
# creating the model lr = LogisticRegression() # prediction lr_y_pred = lr.predict(x_test) # prediction score lr_score = lr.score(x_test, y_test)
Отчет о логистической классификации и матрица путаницы
# Classification report and confusion matrix for Logistic Classification from sklearn.metrics import confusion_matrix, classification_report lr_confusion = confusion_matrix(y_test,lr_y_pred) print(f'Confusion matrix: \n{lr_confusion}\n\n') print(f'Classification Report: \n{classification_report(y_test,lr_y_pred)}') Confusion matrix: [[45 0 0 0 0 0 0 0 0 0] [ 0 49 0 0 0 0 0 0 2 1] [ 0 2 49 2 0 0 0 0 0 0] [ 0 0 0 52 0 0 0 0 1 1] [ 0 0 0 0 47 0 0 1 0 0] [ 0 0 0 0 0 55 0 0 0 2] [ 0 1 0 0 0 0 59 0 0 0] [ 0 0 0 1 1 0 0 51 0 0] [ 0 3 1 0 0 0 0 0 53 4] [ 0 0 0 0 0 1 0 0 1 55]] Classification Report: precision recall f1-score support 0 1.00 1.00 1.00 45 1 0.89 0.94 0.92 52 2 0.98 0.92 0.95 53 3 0.95 0.96 0.95 54 4 0.98 0.98 0.98 48 5 0.98 0.96 0.97 57 6 1.00 0.98 0.99 60 7 0.98 0.96 0.97 53 8 0.93 0.87 0.90 61 9 0.87 0.96 0.92 57 accuracy 0.95 540 macro avg 0.96 0.96 0.96 540 weighted avg 0.96 0.95 0.95 540 # heatmap of Logistic Classifier plt.figure(figsize=(8,6)) sns.heatmap(lr_confusion,square=True, annot=True,cmap='nipy_spectral_r', fmt='d', cbar=True) plt.title('Confusion Matrix for Logistic Classification ',fontsize = 15) plt.xlabel('Predicted label', fontsize =15) plt.ylabel('True label', fontsize =15)
# score lr_score = lr.score(x_test, y_test) print('Accuracy Score of Logistic Classifier:',(lr_score*100)) Accuracy Score of Logistic Classifier: 95.37037037037037
Логистический классификатор обеспечивает точность 97,40 %
4. Классификатор случайного леса
# creating the module rf = RandomForestClassifier() # fitting the model rf.fit(x_train,y_train) # prediction rf_y_pred = rf.predict(x_test) # prediction score rf_score = rf.score(x_test, y_test)
Отчет о классификации и матрица путаницы для случайного леса
# Classification report and confusion matrix for Random forest from sklearn.metrics import confusion_matrix, classification_report rf_confusion = confusion_matrix(y_test,rf_y_pred) print(f'Confusion matrix: \n{rf_confusion}\n\n') print(f'Classification Report: \n{classification_report(y_test,rf_y_pred)}') Confusion matrix: [[45 0 0 0 0 0 0 0 0 0] [ 0 51 0 0 0 1 0 0 0 0] [ 1 1 51 0 0 0 0 0 0 0] [ 0 0 0 54 0 0 0 0 0 0] [ 0 0 0 0 46 0 0 2 0 0] [ 0 0 0 1 0 55 1 0 0 0] [ 0 0 0 0 0 0 60 0 0 0] [ 0 0 0 0 0 0 0 53 0 0] [ 0 1 0 1 0 0 0 1 58 0] [ 0 0 0 1 0 0 0 0 0 56]] Classification Report: precision recall f1-score support 0 0.98 1.00 0.99 45 1 0.96 0.98 0.97 52 2 1.00 0.96 0.98 53 3 0.95 1.00 0.97 54 4 1.00 0.96 0.98 48 5 0.98 0.96 0.97 57 6 0.98 1.00 0.99 60 7 0.95 1.00 0.97 53 8 1.00 0.95 0.97 61 9 1.00 0.98 0.99 57 accuracy 0.98 540 macro avg 0.98 0.98 0.98 540 weighted avg 0.98 0.98 0.98 540 # Heatmap for Random Forest Classifier plt.figure(figsize=(8,6)) sns.heatmap(rf_confusion,square=True, annot=True,cmap='nipy_spectral_r', fmt='d', cbar=True) plt.title('Confusion Matrix for Random Forest Classifier',fontsize = 15) plt.xlabel('Predicted label', fontsize =15) plt.ylabel('True label', fontsize =15)
# score rf_score = rf.score(x_test, y_test) print('Accuracy Score of Random Forest Classifier:',(rf_score*100)) Accuracy Score of Random Forest Classifier: 97.96296296296296
Классификатор случайного леса обеспечивает точность 97,96 %
Некоторые ученые утверждают, что они точно предсказывают цифру в 95 % случаев. Поэтому нам нужно найти среднее значение всех 4 классификаторов, чтобы обосновать эту гипотезу
# calculating mean for all 4 classifier avg_accuracy = (svc_score+lr_score+knn_score+rf_score)/4 print(f'Mean accuracy of all the classifier is:',round(avg_accuracy,4)*100) Mean accuracy of all the classifier is: 97.64
Наши классификаторы дают среднюю точность 97,5 %
Заключение:
Этот набор данных предсказывает цифры в 97,5% случаев, поэтому мы можем сделать вывод, что результаты согласуются с нулевой гипотезой.
Спасибо!
Ссылка на Github: https://github.com/lawish/Suven-Consultants-technology-internship/blob/main/Recognizing%20Handwriting%20Digits%20(1).ipynb
